Kailh Deep Sea Silent Box Switch
Kailh Deep Sea Silent Box Switch - Red (White Stem) / 110 Switches is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Each Kailh Deep Sea Silent Box Switch Set comes with 110 switches and the bottle.
Stable And Silent
The Kailh Deep Sea Silent Box Switch is a special kind of silent switch. Its stem, purple cover, and light purple housing base are precisely polished to minimize friction when working and deliver a stable, silent typing experience. It is available in both tactile and linear.
Double Noise Reduction
The switch’s damper adopts an independent soft rubber (TPE) structure, which mitigates both downstroke and upstroke noise to offer double noise reduction. According to the test data statistics from the Kailh lab, the sound level of this silent switch when triggered is equivalent to decibels measured at a depth of 100 meters in the deep sea if the keycap is installed.
PC And POM Stem Alternative
The stem comes in two materials, PC and POM, each of which will offer you a different typing experience. The PC stem has better light transmittance allowing for a better backlight effect, whereas the POM stem brings a smoother feel.
Upgraded Light Guide
An improved tapered LED window prevents keycap compatibility issues and solves the problem that the switch jam certain keycap.
Large Impact Contact Area
There is a large impact contact area to eliminate vibration and reduce noise reduction to deliver a stable and ultra-quiet feel.
Product Structure
Feature And Specs
Name | Box Red Switch (White Stem) |
---|---|
Type | Linear |
Operation Force | 50±10 gf |
Pre-travel | 1.8±0.4 mm |
Return Force | ≥15 gf |
Total Travel | 3.6±0.3 mm |
Sound Level | Silent |
Operation Life | Up to 100M cycles |
Suitable For | Gaming/office |
Name | Box Red Switch (Transparent Stem) |
---|---|
Type | Linear |
Operation Force | 50±10 gf |
Pre-travel | 1.8±0.4 mm |
Return Force | ≥15 gf |
Total Travel | 3.6±0.3 mm |
Sound Level | Silent |
Operation Life | Up to 100M cycles |
Suitable For | Gaming/office |
Name | Box Brown Switch |
---|---|
Type | Tactile |
Operation Force | 45±10 gf |
Pre-travel | 2.0±0.4 mm |
Return Force | ≥15 gf |
Total Travel | 3.6±0.3 mm |
Sound Level | Silent |
Operation Life | Up to 100M cycles |
Suitable For | Midway gaming/office |
Product Name | Deep Sea Silent Box Switch |
---|---|
Stem | POM |
Top Housing | PC |
Bottom Housing | Nylon |
Contact | Composite gold |
Spring | Spring steel |
Protecting Cover | Nylon |
Slider | POM |
Light Guide Post | PC |
Pins | 3-Pin |
Factory Pre-lubed | No |
SMD LED Support | Yes |
Compatible Keychron Keyboard:
Any K series (Gateron Mechanical Hot-Swappable or Keychron Mechanical Hot-Swappable versions only), K Pro series (Normal-profile versions only), C and C Pro series (Hot-Swappable versions only), V series, Q series and Q Pro series Keychron keyboards.
