Keychron Q6 Max QMK/VIA Wireless Custom Mechanical Keyboard ISO Layout Collection


Layout Version

The Fully Assembled version includes:
  •  The keyboard PCB, the case, and the PC plate.
  • Keycaps (included Mac & Windows keycaps).
  • Switches.
No discount codes can be used for the Q6 Max ISO.

Keychron Q6 Max
ISO Layout Collection

Keychron Q6 Max QMK/VIA Wireless Custom Mechanical Keyboard ISO Layout Collection

Introducing the Keychron Q6 Max ISO, a full-metal QMK/VIA wireless customized mechanical keyboard with a full-size layout and support for 2.4 GHz wireless, Bluetooth 5.1, and Type-C wired connectivity. The combination of reinforced multi-layer acoustic foam and double-gasket design provides an incredibly satisfying typing experience while ensuring a superior sound quality.

Features of Q6 Max

Q6 Max ISO Layout Versions

These versions include the UK, German, Swiss, and Nordic layouts, all with extra keycaps suitable for Mac and Windows devices.

🇬🇧 UK-ISO Layout

Q6 Max UK-ISO Layout

🇩🇪 German DE-ISO Layout

Q6 Max DE-ISO Layout

🇨🇭Swiss-ISO Layout

Q6 Max Swiss-ISO Layout

🇩🇰 🇫🇮 🇳🇴 🇸🇪 Nordic-ISO Layout

Q6 Max Nordic-ISO Layout
Customize Your Q3 Pro

Choose the keycaps, switches and more accessories for your Q3 Pro

2.4 GHz & Bluetooth Connection

Experience peak gaming performance on the fly with the 2.4 GHz wireless connection boasting a rapid 1000 Hz polling rate. For seamless multitasking across your computer, phone, and tablet, you can effortlessly connect the Q6 Max via Bluetooth 5.1 to three devices.

Keychron Q6 Max QMK/VIA Wireless Custom Mechanical Keyboard ISO Layout Collecti

A Refined Piece Of Metal Art

The entire metal body is crafted with 6063 aluminum that is processed through CNC machined, polished, sandblasted, and undergoes 24 more manufacturing stages to make this solid metal piece of art that is the Q6 Max.

Keychron Q6 Max QMK/VIA Wireless Custom Mechanical Keyboard ISO Layout Collecti

Significantly Enhanced Acoustic Foams

Elevate the typing experience with a combination of premium acoustic foams such as IXPE, PET, and Latex. Each keystroke becomes enjoyable, making every tap a delight for the senses.

Easy Assemble

We designed every component to be able to assemble easily so you can customize and adjust each component with ease to create your ultimate typing experience.

Component of Keychron Q6 Max QMK/VIA Wireless Custom Mechanical Keyboard ISO Layout Collection
Component of Keychron Q6 Max QMK/VIA Wireless Custom Mechanical Keyboard ISO Layout Collection
An Epic Core Inside The Keyboard

An Epic Core Inside The Keyboard

A powerful ARM Cortex-M4 chip (MCU) equipped with 256K Flash will provide more flexibility for developers. The polling rate is 1000 Hz right out of the box on 2.4 GHz and wired modes (90 Hz on Bluetooth mode), which makes the latency hardly noticeable even in competitive games.

Double-Gasket Design

The Double Gasket Design is a new innovative structure in the industry. In addition to the gaskets on the plates, we added silicone pads between the top and bottom cases to significantly reduce the acoustic resonance between the metals and reduce the noise of the impacted metals.

Double-Gasket Design
Keychron Q6 Max QMK/VIA Wireless Custom Mechanical Keyboard ISO Layout Collection

Experience the next level of key sounds and comfort with our gasket mount design together with a flexible PC (Polycarbonate) plate. This design combination allows the keyboard to maintain the flexibility of the gasket structure and improves the overall typing sound.

OSA Double-Shot PBT Keycaps

OSA Double-Shot PBT Keycaps

To further fine-tune your typing experience, the Q6 Max ISO comes with our unique OSA profile (OEM profile with spherical-angle) and double-shot PBT keycaps that aim to provide a more comfortable fingertip feel with excellent oil resistance for long-term use on the TKL layout.

Suitable for All Devices

Built with the Mac users’ experience in mind while still retaining compatibility for Windows devices, the Q6 Max comes with a system toggle and an additional set of customized keycaps for both Windows and macOS systems. You can now save two different layouts on the keyboard, one for each system.

Q6 Max windows keycaps
OS toggle

Program The Q6 Max with QMK & VIA.

Endless possibilities for a fluid workflow thanks to its ability to remap any key, and create macro commands, shortcuts, or key combinations through the QMK/VIA.

Check out the video above demonstrating how to remap the F16 key to an Eject key with the VIA software to create a shortcut to put your Mac to sleep (Command-Option-Eject).

Get the Q6 Max keymap working on VIA

Since the VIA code for the Q6 Max is still awaiting approval from Github, it is not yet automatically recognized. Please download the appropriate keymap JSON file below, open VIA, turn on "Show Design tab" on "Settings" tab, and drag the JSON file into the “Design” tab on VIA to get the Q6 Max keymap working on VIA.


Every detail matters for a personalized typing experience, that’s why we give you the power. You can hot-swap every switch on the Q6 Max with almost all of the 3pin and 5pin MX style mechanical switches on the market (including Cherry, Gateron, Kailh, Panda, etc.) without soldering required. You can customize your own typing experience in seconds.

Keychron Q6 Max ISO Hot-Swappable

South-Facing RGB

Comes with 22 types of RGB backlight settings. You can further fine-tune the RGB hue, saturation, brightness, effect speed, and different modes, or even remap these keys with QMK/VIA.

Gateron Jupiter Switch

Our exclusive Gateron Jupiter mechanical switch (for the Fully Assembled version only) comes with a 3-pin design, its pre-lubed with a reliable Gateron quality standard with up to 80 million keystrokes lifespan. While their unique LED diffuser design offers high RGB backlight transmittance and softer backlight effect.

The banana switch provides an early tactile bump at the top with a uniquely smooth experience like those Panda switches on the market.

Gateron Jupiter Switch Features
PCB Stabilizers

PCB Stabilizers

No detail is too insignificant when it comes to your fingertip feel. We’ve integrated the PCB-mounted screw-in stabilizers for a smoother typing experience with less wobbliness on the big keys such as the space bar, shift, enter, and delete keys. You can even customize your favorite stabilizers on your own.

What's in the box?

Packing list for Q6 Max ISO fully assembled knob version


Width137 mm
Length446 mm
Front Height20.1 mm  (without keycaps)
Back Height32.6 mm (without keycaps)
Feet Height2.7 mm
Weight2184 g ± 10 g (Fully Assembled version)
Body MaterialAluminum
StabilizerScrew-in PCB stabilizer
KeycapsKSA double-shot PBT keycaps, not shine-through (Fully Assembled version)
SwitchesGateron Jupiter (Fully Assembled version)
BacklightSouth-facing RGB LED
Switch SupportYes. Compatible with most of the 3 pin & 5 pin MX mechanical switches such as Gateron, Cherry MX and Kailh, etc.
MCUUltra-low-power ARM Cortex-M4 32-bit STM32L432 (128KB Flash)
Polling Rate 1000 Hz (wired) / 90 Hz (wireless)
N-Key Rollover (NKRO)Yes for both wireless and wired modes
Operating Environment-10 to 50℃
Battery4000 mAh Rechargeable li-polymer battery
BT Working Time (Backlit off)Up to 180 hours (Lab test result may vary by actual use)
BT Working Time (RGB)Up to 100 hours (Lowest brightness)
Bluetooth Version5.1
Compatible SystemmacOS/Windows/Linux
Bluetooth Device NameKeychron Q6 Max
Connectivity2.4 GHz / Bluetooth / Type-C wired
Keychron Q6 Max User Guide

Learn more about the Keychron Q6 Max such as the Q6 Max shortcuts, assembling the Q6 Max, factory reset, and more in the FAQ section.
