Keychron Q3 Max QMK/VIA Clavier mécanique personnalisé sans fil Collection de mises en page ISO

UGS : Q3M-M1-UK
€209,00

Type
Layout Version
Switches

La version entièrement assemblée comprend :
  •  Le PCB du clavier, le boîtier et la plaque PC.
  • Touches (inclus les touches Mac et Windows).
  • Commutateurs.



Options ISO : allemand, nordique, britannique, suisse.

Aucun code de réduction ne peut être utilisé pour le Q3 Max.

Keychron Q3 Max

ISO Layout Collection

Q3-Max-ISO

The Q3 Max Keyboard, featuring an 80% TKL layout, combines advanced 2.4G wireless, Bluetooth, and Type-C wired connectivity, enhances workspaces by reducing clutter and facilitating efficient remote work. Its upgraded acoustic foam not only ensures quieter typing but also elevates the tactile experience, making each keystroke smoother and more refined.

Features of Q1 Max
Customize Your Q3 Max ISO

Choose the keycaps, switches, and more accessories for your Q3 Max ISO

Q3 Max ISO Layout Versions

These versions include the UK, German, Swiss, and Nordic layouts, all with extra keycaps suitable for Mac and Windows devices.

🇬🇧 UK-ISO Layout

q3-max-uk-keycaps

🇩🇪 German DE-ISO Layout

q3-max-german-keycaps

🇨🇭Swiss-ISO Layout

q3-max-swiss-keycaps

🇩🇰 🇫🇮 🇳🇴 🇸🇪 Nordic-ISO Layout

q3-max-nordic-keycaps

2.4 GHz & Bluetooth Connection

Discover enhanced performance with the Q3 Max Keyboard, featuring a 2.4 GHz wireless connection and a rapid 1000 Hz polling rate for responsive use. It also offers Bluetooth 5.1 connectivity, allowing easy and efficient multitasking by connecting with up to three devices, such as your computer, phone, and tablet, with quick switching capability.

Q3-Max-ISO

A Refined Piece Of Metal Art

The entire metal body is crafted with 6063 aluminum that is processed through CNC machined, polished, sandblasted, and undergoes 24 more manufacturing stages to make this solid metal piece of art that is the Q3 Max.

Q3-Max-ISO

Significantly Enhanced Acoustic Foams

Elevate the typing experience with a combination of premium acoustic foams such as IXPE, PET, and Latex. Each keystroke becomes enjoyable, making every tap a delight for the senses.

Easy Assemble

We designed every component to be able to assemble easily so you can customize and adjust each component with ease to create your ultimate typing experience.

Q3-Max-ISO-Structure-mobile
Q3-Max-ISO

An Epic Core Inside The Keyboard

A powerful ARM Cortex-M4 chip (MCU) equipped with 256K Flash will provide more flexibility for developers. The polling rate is 1000 Hz right out of the box on 2.4 GHz and wired modes (90 Hz on Bluetooth mode), which makes the latency hardly noticeable even in competitive games.

Double-Gasket Design

The Double Gasket Design is a new innovative structure in the industry. In addition to the gaskets on the plates, we added silicone pads between the top and bottom cases to significantly reduce the acoustic resonance between the metals and reduce the noise of the impacted metals.

Double-Gasket Design
Q3-Max-ISO

Experience the next level of key sounds and comfort with our gasket mount design together with a flexible PC (Polycarbonate) plate. This design combination allows the keyboard to maintain the flexibility of the gasket structure and improves the overall typing sound.

OSA Double-Shot PBT Keycaps

To further fine-tune your typing experience, the Q3 Max ISO comes with our unique OSA profile (OEM profile with spherical-angle) and double-shot PBT keycaps that aim to provide a more comfortable fingertip feel with excellent oil resistance for long-term use on the TKL layout.

ISO-OSA-PBT-keycaps
Keychron Q3 Max QMK VIA Custom Mechanical Keyboard

Switch layouts between macOS & Windows

Built with the Mac users’ experience in mind while still retaining compatibility with Windows devices, the Keychron Q3 Max comes with a system toggle and an additional set of customized keycaps for both Windows and macOS systems. You can now save two different layouts on the keyboard, one for each system.

Programmable Knob

Designed to enhance your creative workflow, the aluminum rotary encoder allows you to easily
 customize your favorite keys and macros on the knob through the VIA software.

Rotary encoder function of Keychron Q3 Max Custom

You can easily customize the Q3 Max's knob to your desired key or macro commands
such as: zooming in/out, adjusting screen brightness, brush size, volume, selecting video clips or photos, or backlight hue.

 Setting the macros for "zoom in/out"

Using the knob as "zoom in/out"

pfLauncher

Program with QMK & Launcher.

The open-source QMK firmware means endless possibilities for key remapping, macros, shortcuts, and more. Now you can easily customize each key with the Keychron Launcher web app.

Program the K14 Pro keyboard with Launcher
Click here to use Keychron Launcher

*Please use the latest version of Chrome / Opera / Edge browser to open the Launcher and connect the keyboard to your device via wired mode.

pf-c56a5ee9--via1

Program Q3 Max with QMK & VIA

With full QMK and VIA support, you can easily program and remap each key on the keyboard. The open-source firmware means endless possibilities for keyboard layouts, shortcuts, backlight effects, even the knob, and more.

Check out the video above demonstrating how to remap the RGB Mode + key to an Eject key with the VIA software to create a shortcut to put your Mac to sleep (Command-Option-Eject).

Get the Q3 Max keymap working on VIA

Since the VIA code for the Q3 Max is still awaiting approval from Github, it is not yet automatically recognized. Please download the appropriate keymap JSON file below, open VIA, turn on "Show Design tab" on "Settings" tab, and drag the JSON file into the “Design” tab on VIA to get the Q3 Max keymap working on VIA.

Download Q3 Max Knob
ISO Keymap JSON File
Keychron Q1 Max ISO Hot-Swappable

Hot-Swappable

The hot-swappable sockets are mounted on the PCB, so you can install or change the switches without soldering. The PCB supports both 3 pin and 5 pin MX mechanical switches.

South-facing RGB LED Lights

The south-facing RGB LED is designed to better illuminate the keyboard backlight from the typist’s angle with the premium non-shine-through PBT keycaps installed. The south-facing RGB is also free from interference when the users install OEM or Cherry-profile alternative keycaps on the keyboard.

Gateron Jupiter Switch

Our exclusive Gateron Jupiter mechanical switch (for the Fully Assembled version only) comes with a 3-pin design, its pre-lubed with a reliable Gateron quality standard with up to 80 million keystrokes lifespan. While their unique LED diffuser design offers high RGB backlight transmittance and softer backlight effect.

Gateron Jupiter Switch Features
PCB Stabilizers

All New Screw-in PCB Stabilizers

The screw-in design increases stability and makes it easier for changes and upgrades. Precise craftsmanship makes the stabilizers more stable and less shaky. The big keys’ (space bar, shift, enter, backspace) typing experience is now more stable and smooth. The Keychron Q3 Max also supports third-party screw-in PCB stabilizers.

What's in the box?

Package-list-of-Q3-Max-ISO.jpg.jpg__PID:b1fb4ff2-3389-4503-82c4-c783986f7f09
Differences Among the Q Max, Q Pro, and Q Series Keyboards

Specs

Width137 mm
Length365 mm
Front Height19.7 mm (without keycaps)
Back Height32.6 mm (without keycaps)
Feet Height2.7 mm
Angle5.2°
Weight2045g ± 10g (Fully Assembled Version)
Body MaterialAluminum
Plate MaterialPC
Polling Rate1000 Hz (2.4 GHz & wired) / 90 Hz (Bluetooth)
Backlight 22 types of RGB backlight options plus endless possibilities
Operating Environment-10℃ to 50℃
Battery4000 mAh Rechargeable li-polymer battery
Keycaps (Fully Assembled Version)OSA double-shot PBT keycaps, not shine-through (Fully Assembled version)
MCUARM Cortex-M4 32-bit STM32F402 (256KB Flash)
SwitchesGateron Jupiter (Fully Assembled version)


BacklightSouth-facing RGB LED
Switch SupportHot-swappable (5 pin & 3 pin)
StabilizerScrew-in PCB stabilizer
Connectivity2.4 GHz/Bluetooth/ Type-C wired
CableType-C cable + Type-A to Type-C adapter
Charging Time  Around 5 hours
Bluetooth Device NameKeychron Q3 Max


Cable Length 1.8 m
Wireless Working Time (Backlit off)Up to 180 hours (Lab test result may vary by actual use)


Wireless Working Time (RGB)Up to 100 hours (Lowest brightness)
Bluetooth Version 5.1
Compatible SystemmacOS/Windows/Linux
Charging PortUSB type-C
N-Key Rollover (NKRO) Yes for both wireless and wired modes
 Hot-swappable  Yes. Compatible with most of the 3 pin & 5 pin MX mechanical switches such as Gateron, Cherry MX and Kailh, etc.
Keychron Q3 Max User Guide

Learn more about the Keychron Q3 Max such as the Q3 Max shortcuts, assembling the Q3 Max, factory reset, and more in the FAQ section.
